Low price Powerful BM1500 Double drum ride-on roller Global supplier

Dimensions
Working Width	mm	930
Overall Length (Guard Frame Tilted/Upright)	mm	1980/1940
Overall Height (Guard Frame Tilted/Upright)	mm	1540/2125
Outer Turning Radius	mm	2800
Steel Wheel Width	mm	800
Steel Wheel Diameter	mm	560
Wheelbase	mm	1356

Inquire Now

Model BM1500 BM1600 Weight Operating Weight kg 1450 1530 Static Load n/cm 69.5/68 Dimensions Working Width mm 930 Overall Length (Guard Frame Tilted/Upright) mm 1980/1940 Overall Height (Guard Frame Tilted/Upright) mm 1540/2125 Outer Turning Radius mm 2800 Steel Wheel Width mm 800 Steel Wheel Diameter mm 560 Wheelbase mm 1356 Drive Engine Brand Changchai / Honda Kubota Engine Model 192F 195F / 390 Z482 Engine Type Single – cylinder, Air – cooled, Four – stroke Diesel Engine Two – cylinder Water – cooled Number of Cylinders pc 1 Output Power kw 8.1 Rotation Speed rpm 3600 Electrical Equipment V 12 Drive Mode Variable Piston Pump Stepless Speed Change Dual – wheel Drive Motor Series Connection Travel Characteristics Speed km/h 0 – 5 Theoretical Climbing Ability % 30 Braking Service Brake Variable Piston Pump Steering Steering Mode Hydraulic Steering Steering System Swing Hinge Type Excitation System Vibrating Steel Wheel Front Drive Form Hydraulic Motor Vibration Frequency hz 65 Vibration Amplitude mm 0.5 Exciting Force kn 22 Water Spraying System Form Intermittent Pressure Water Spraying Capacity Hydraulic Oil Capacity L 22 Fuel Capacity L 5.5 Water Tank Capacity L 65

Model		BM1500	BM1600
Weight
Operating Weight	kg	1450	1530
Static Load	n/cm	69.5/68
Dimensions
Working Width	mm	930
Overall Length (Guard Frame Tilted/Upright)	mm	1980/1940
Overall Height (Guard Frame Tilted/Upright)	mm	1540/2125
Outer Turning Radius	mm	2800
Steel Wheel Width	mm	800
Steel Wheel Diameter	mm	560
Wheelbase	mm	1356
Drive
Engine Brand		Changchai / Honda	Kubota
Engine Model		192F 195F / 390	Z482
Engine Type		Single – cylinder, Air – cooled, Four – stroke Diesel Engine	Two – cylinder Water – cooled
Number of Cylinders	pc	1
Output Power	kw	8.1
Rotation Speed	rpm	3600
Electrical Equipment	V	12
Drive Mode		Variable Piston Pump Stepless Speed Change	Dual – wheel Drive Motor Series Connection
Travel Characteristics
Speed	km/h	0 – 5
Theoretical Climbing Ability	%	30
Braking
Service Brake		Variable Piston Pump
Steering
Steering Mode		Hydraulic Steering
Steering System		Swing Hinge Type
Excitation System
Vibrating Steel Wheel		Front
Drive Form		Hydraulic Motor
Vibration Frequency	hz	65
Vibration Amplitude	mm	0.5
Exciting Force	kn	22
Water Spraying System
Form		Intermittent Pressure Water Spraying
Capacity
Hydraulic Oil Capacity	L	22
Fuel Capacity	L	5.5
Water Tank Capacity	L	65

Full details

FAQ

01

Why should I choose you?

Firstly, we choose good condition and less hour used original machines for customers. Secondly, we are available for the third party to inspect.Thirdly, all machinery is available for your final inspection on site or live video call.Last, we also provide pre-sale /after-sale service and long-term spare parts support.
02

How do you ensure the quality of your products?

Hua Chunqiang has a comprehensive and strict quality inspection process and regular maintenance, you can choose the way of inspection before shipment, or seek the help of a third-party verification company.
03

What is your delivery time?

Huachunqiang has an independent logistics system to improve freight efficiency and shorten delivery time. Delivery time (for most products, it is between 7 and 15 days. If you have special requirements, the transportation time can be reasonably extended).
04

WHATIS YOUR PAYMENT TERM ?

Hua Chunqiang has established a comprehensive collection and disbursement system to serve as many customers as possible, and we accept wire transfers, sight letters of credit, Western Union, PayPal, and more!
