    S12H MOBILE SCREENER
    S12H MOBILE SCREENER

    High Efficiency Hydraulic S12H MOBILE SCREENER Durable Equipment Global Supplier

    PRODUCTMODEL S12H
    Driven mode Hybrid
    Engine power 129kW
    Capacity up to 400/h
    Overall wight 42000kg
    Transportatin dimension (LxW×H) 20m × 2.99m x 3.48m
    Working dimension (LxWxH) 20.95m x 14.5m x 4.5m

    Inquire Now

    Contact Us

    Share :

    • Description

    • Logistics & Stock

    The S12H is primarily used for the screening of materials in the later stages,utilizing different mesh specifications to separate materials of various sizes.The materials are transported via a conveyor belt to different locations for stacking.

    ADVANTAGES AND FEATURES
    Hybrid power,allowing for seamless switching between grid power and diesel generator drive
    Quick-folding side belts for easy relocation,meeting production needs during frequent relocations
    Complies with EU Stage V emission standards,promoting energy conservation and emission reduction
    Three-deck screening to obtain various sizes of materials
    High material handling capacity,reaching up to 400 t/h
    High-power vibrating motor for enhanced screening efficiency

    Hopper/feederScreen BoxFine conveyorMedium-Grade conveyorMedium-Coarse conveyorPower unitCoarse conveyor
    Hopper capacity:3.4m3Capacity:up to 400t/hBelt width:900mmBelt width:900mmBelt width:900mmEngine power:129kWBelt width:1000mm
    Feed height:2500mmPower:30kWDischarge height:3895mmDischarge height:3895mmDischarge height:3980mmTank capacity:300LDischarge height:3900mm
    Feed in width:1200mmScreening area:12m2Fuel consumption:13-17L/h
    Max feeding size:200mmStageV
    S12H MOBILE SCREENER

    Remarks:
    1.Screen processing capacity is related to materal humidity,feed size and discharge size.
    2.Three power options:diesel hydraulic,hybrid.electric.
